DR1800FZ-FM Rotary arm wrapping machine with top sheet dispenser

Share to:
sharethis sharing button
This machine is standard rotary arm wrapping machine add top sheet dispenser function.
wrapping machine will cover a sheet of film on the top of product automatically,this could make product for better waterproof and dustproof
It most widely use in Chemical and beverage,glass industry
Quantity:
Model DR1800FZ-FM
Wrap size (L X W) (500-1200)mm X (500-1300)mm
Wrap height (max) 1800mm or customized
Rotary speed 0-15rpm adjustable    >30 Pallets/Hour
Film carriage Power pre-stretch system up to 250% with adjustable speed
Cut & clamp unit Pneumatic control
Pneumatic system 0.6-0.8Mpa 200NL/min
Lift system Lift speed adjustable
Top sheet film outfeed length Adjustable
Conveyor Height:500mm; Speed:8-15m/min; Weight capacity:2000kg
Control system PLC control, wrap layers adjustable, photo-eyes auto-height sensing

Machine size (LXWXH) 4500mmX 2200mm X 4300mm
Power/voltage Rotary arm:0.75kw  Film carriage:0.37kw  Lift system: 0.37kw   AC380V 50HZ 3P

Package material
Top sheet film PVC
Width 1200-1800mm
Dia. 100-300mm
Thickness 50-100mic
Wrapping film LLDPE film
Width 500mm
Thickness 23-30mic

Top press Optional
Pressure 0-30kg
Safety guard Optional
