This machine is most widely one used in different industry,it’s a semi-automatic model,this needs operator to fix the film on the product manually.
Model K1100 Wrap size (L X W) (500-1200)mm X (500-1100)mm Wrap height (max) 2400mm Turntable diameter 1650mm Turntable rotary speed 0-12rpm adjustable by inverter Turntable height 78mm Turntable weight capacity (max) 2000Kg Film carriage Power pre-stretch system up to 250% with adjustable speed Wrap efficiency 20-40 Pallets/Hour Mast(lift system) Film carriage lift speed adjustable by inverter Control system PLC control
Model K1100 Wrap size (L X W) (500-1200)mm X (500-1100)mm Wrap height (max) 2400mm Turntable diameter 1650mm Turntable rotary speed 0-12rpm adjustable by inverter Turntable height 78mm Turntable weight capacity (max) 2000Kg Film carriage Power pre-stretch system up to 250% with adjustable speed Wrap efficiency 20-40 Pallets/Hour Mast(lift system) Film carriage lift speed adjustable by inverter Control system PLC control
Total weight(max) 450kg Power/voltage Turntable:0.75kw Film carriage:0.37kw Mast: 0.37kw/ AC220V 50HZ Machine size 2460mm X 1650mm X 2700mm
Total weight(max) 450kg Power/voltage Turntable:0.75kw Film carriage:0.37kw Mast: 0.37kw/ AC220V 50HZ Machine size 2460mm X 1650mm X 2700mm
Ramp Optional Top plate Optional
Ramp Optional Top plate Optional
